X-ray imaging inspection apparatus manufactured by Softex
Features
- Multi-device capable of both film shooting and digital sensor shooting
- Widely active in universities, research, laboratories etc.
- With digital timer for film shooting
※Test shooting of samples is also accepted, so please feel free to contact us.
Main applications
Small animals and fish bones, wooden nodes, resin fiber flow.
Fish
Tree node
Specification
※スクロールしてご覧いただけます。
| TYPE | M-60 | M-100 | M-150W |
|---|---|---|---|
| Input | AC100V,50/60Hz | ||
| Maximum voltage | 60kV | 100kV | 150kV |
| Maximum current | 3mA | 3mA | 2mA |
| Sensor | Digital sensor * Option | ||
| Appearance dimension | W800×D600×H1,625mm | W680×D900×H1,650mm | |
| Equipment weight | About 300kg | About 400kg | About 800kg |
※External dimensions and weight vary depending on specifications.
